GENERAL

Rx Frequency Range: 30 kHz - 56 MHz (operating) 160 - 6 m (specified performance, Amateur bands only)
Tx Frequency Ranges: 160 - 6 m (Amateur bands only)
Frequency Stability: ±0.5 ppm (after 1 minute @+25 °C) ±1.0 ppm (after 1 minute @–10 °C ~ +50 °C)
Operating Temperature Range: –10 °C ~ +50 °C
Emission Modes: A1A (CW), A3E (AM), J3E (LSB, USB), F3E (FM), F1B (RTTY), F1D (PACKET), F2D (PACKET)
Frequency Steps: 1/10 Hz (SSB, CW, & AM), 100 Hz (FM)
Antenna Impedance: 50 Ohms, unbalanced 16.7 - 150 Ohms, unbalanced (Tuner ON, 160 - 6 m Amateur bands, TX only)
Power Consumption (Approx.):
Rx (no signal) 1.8 A
Rx (signal present) 2.1 A
Tx (100 W) 22 A
Supply Voltage: DC 13.8 V ± 10% (Negative Ground)
Dimensions (WxHxD): 14.4 x 4.5 x 12.4 Weight (Approx.): 28.7 lbs

TRANSMISOR

Power Output: 5 - 100 watts (2 - 25 watts AM carrier)
Modulation Types: J3E (SSB): Balanced, A3E (AM): Low-Level (Early Stage), F3E (FM): Variable Reactance
Maximum FM Deviation: ±5.0 kHz/±2.5 kHz
Harmonic Radiation: Better than –60 dB (160 - 10m Amateur bands: Harmonics) Better than –50 dB (160 - 10m Amateur bands: Others) Better than –65 dB (6m Amateur band) SSB Carrier Suppression: At least 60 dB below peak output
Undesired Sideband Suppression: At least 60 dB below peak output
3rd-order IMD: –31 dB @14 MHz 100 watts PEP
Bandwidth: 3 kHz (LSB/USB), 500 Hz (CW), 6 kHz (AM), 16 kHz (FM)
Audio Response (SSB): Not more than –6 dB from 300 to 2700 Hz
Microphone Impedance: 600 Ohms (200 to 10 k Ohms)

RECEPTOR

Circuit Type: Triple-conversion Superheterodyne
Intermediate Frequencies: 69.450 MHz/450 kHz/30 kHz (24 kHz for AM/FM)
Sensitivity:
SSB (BW: 2.4 kHz, 10 dB S+N/N) 4  (0.5 - 1.8 MHz) (IPO ON)
0.2 µV (1.8 - 30 MHz) (RF AMP 2 ON)
0.125 µV (50 - 54 MHz) (RF AMP 2 ON)
AM (BW: 6 kHz, 10 dB S+N/N, 30% modulation @400 Hz)
28 µV (0.5 - 1.8 MHz) (IPO ON)
2 µV (1.8 - 30 MHz) (RF AMP 2 ON)
1 µV (50 - 54 MHz) (RF AMP 2 ON)
FM (BW: 15 kHz, 12 dB SINAD)
0.5 µV (28 - 30 MHz) (RF AMP 2 ON)
0.35 µV (50 - 54 MHz) (RF AMP 2 ON)
There is no specification for frequency
Squelch Sensitivity: SSB/CW/AM
(RF AMP 2 ON) 2 µV (0.1 - 1.8 MHz) 2 µV (50 - 54 MHz)
FM 1 µV (28 - 30 MHz) 1 µV (50 - 54 MHz)
There is no specification for frequency ranges not listed.
Selectivity (WIDTH: Center): Mode –6 dB –60 dB
CW/RTTY/PKT 0.5 kHz or better 750 Hz or less
SSB 2.4 kHz or better 3.6 kHz or less
AM 6 kHz or better 15 kHz or less
FM 15 kHz or better 25 kHz or less
Image Rejection: 70 dB or better (160 - 10m Amateur bands)
60 dB or better (6m Amateur band)
Maximum Audio Output: 2.5 W into 4 Ohms with 10% THD
Audio Output Impedance: 4 to 8 Ohms (4 Ohms: nominal)
Conducted Radiation: Less than 4 nW

Las especificaciones pueden sufrir cambios.
